Universal Columns

Universal columns, also known as an L-column due to its shape, is a vertically-oriented piece of steel used in construction to resist axial loads.

The term ‘universal column’ is used due to the versatility of this steel in building.

Steel L-columns are designed to be excellent at resisting compression. Unlike a universal steel beam, the width and depth of a universal steel column are roughly equivalent and they have a lower web to flange ratio.

The reduced depth of structural steel universal columns in comparison with steel L-beams is the reason for their widespread use in residential builds such as loft conversions and other situations in which height is too restricted to allow an L-beam.

Designation	Mass per metre	Depth of Section (h)	Width of Section (b)	Thickness Web (s)	Thickness Flange (t)
kg/m	mm	mm	mm	mm	mm
152 x 152	23	152.4	152.2	5.8	6.8
152 x 152	30	157.6	152.9	6.5	9.4
152 x 152	37	161.8	154.4	8	11.5
203 x 203	46	203.2	203.6	7.2	11
203 x 203	52	206.2	204.3	7.9	12.5
203 x 203	60	209.6	205.8	9.4	14.2
203 x 203	71	215.8	206.4	10	17.3
203 x 203	86	222.2	209.1	12.7	20.5
254 x 254	73	254.1	254.6	8.6	14.2
254 x 254	89	260.3	256.3	10.3	17.3
254 x 254	107	266.7	258.8	12.8	20.5
254 x 254	132	276.3	261.3	15.3	25.3
254 x 254	167	289.1	265.2	19.2	31.7
305 x 305	97	307.9	305.3	9.9	15.4
305 x 305	118	314.5	307.4	12	18.7
305 x 305	137	320.5	309.2	13.8	21.7
305 x 305	158	327.1	311.2	15.8	25
305 x 305	198	339.9	314.5	19.1	31.4
305 x 305	240	352.5	318.4	23	37.7
305 x 305	283	365.3	322.2	26.8	44.1
356 x 368	129	355.6	368.6	10.4	17.5
356 x 368	153	362	370.5	12.3	20.7
356 x 368	177	368.2	372.6	14.4	23.8
356 x 368	202	374.6	374.7	16.5	27
356 x 406	235	381	394.8	18.4	30.2
356 x 406	287	393.6	399	22.6	36.5
356 x 406	340	406.4	403	26.6	42.9
356 x 406	393	419	407	30.6	49.2
356 x 406	467	436.6	412.2	35.8	58
356 x 406	551	455.6	418.5	42.1	67.5
356 x 406	634	474.6	424	47.6	77

The quality of our universal steel beams and joists

Our steel fabrication service is the result of skilled craftsmanship and the experience of a team of highly-qualified professionals with nearly 50 years of industry experience.

All our steel is manufactured in our own workshops and is CARES approved. All the structural steel we produce has original manufacturer’s test certification and meets BS EN ISO 9002 requirements.

Our steelwork is manufactured to British Standards BS 8666 and BS 4466 and all our welding, drilling and steelwork fabrication is compliant with CE Marking standards.

WHY CHOOSE CANNON STEELS?

At Cannon Steels we provide structural steel universal columns in a range of sizes to suit any build requirement.

However specialised the requirements of your build, we have the equipment and expertise to cater to them. We are ideally situated to supply structural steel across North London and the surrounding areas.

We have invested in our delivery service to ensure over 90% of our deliveries arrive within 48 hours of placing your order.

Every lorry in our fleet is fitted with a crane and safety is our top priority – all of our drivers hold third party offloading accreditations to guarantee that your steel are offloaded smoothly and safely.

Don’t hesitate to get in touch with our expert team who will be happy to help you find the specialist steel to meet your exact build requirements.
